3D product configurator examples—from visual choice to usable project data.

What changes

Width, projection, height, wall-mounted or freestanding structure, roof zones, louvre orientation, posts, gutters, screens, sliding glass, lighting, heating and frame finish.

Rules to protect

Dimension limits depend on the selected system and bay count. Screens need a supported opening, glass needs a compatible track, accessories require electrical or structural conditions and linked roof zones must remain buildable.

Price and action

Base system plus dimensional formulas, bay quantities, posts, roof mechanisms, side products, finish surcharges, installation, delivery and tax according to the market and user role. Save the design, request a quote, continue with a salesperson, review it in AR or create a proposal, depending on the sales journey.

Required output

A project record with dimensions, selected system, accessories, price revision, images, quote lines and optional bill-of-materials or order data defined in scope.

What changes

Overall width, projection, wall height, front height, roof pitch, post positions, frame finish, glass specification, gutter, lighting, fixed sides and sliding-door panels.

Rules to protect

Pitch, span, glass panel widths, post spacing, drainage and door openings must stay inside the selected system limits. A side wall or door set must match the actual opening geometry.

Price and action

Frame dimensions, rafter and glass quantities, side elevations, doors, finish, accessories, survey, delivery and installation can feed one calculation with market-specific taxes. Request a measured survey, save a preliminary design or issue a quote clearly marked with the assumptions that still require site verification.

Required output

Configured elevations, dimensions, selected glass and frame system, price, proposal imagery and the fields needed for survey or technical review.

What changes

Awning family, width, projection, cassette, arm type, frame colour, fabric collection, valance, motor, controls, wind sensor, lighting and mounting condition.

Rules to protect

Available projections depend on width and model. Fabric availability can vary by collection, motor and lighting options may require particular cassette types, and mounting must match the defined installation surface.

Price and action

Model and size matrix, fabric group, motorization, sensors, lighting, brackets, delivery and installation form the commercial result. Add to an ecommerce basket for standard products or request a survey and quote for made-to-measure installation.

Required output

Selected model, dimensions, fabric code, motor and accessory package, calculated price and a visual reference for the customer and installer.

What changes

Opening size, frame and slab system, handing, sidelights, transom, panel design, inside and outside finish, glazing, handle, lock, threshold and installation package.

Rules to protect

Overall sizes, leaf ratios, glass panels, hardware, fire or security classifications and threshold options depend on the selected construction and market requirements.

Price and action

System, dimensions, panels, glazing, hardware, finish, security package, survey, delivery and installation can be combined with dealer or retail price lists. Save a door design, request a measured quotation, send it to a dealer or proceed to checkout where the catalogue supports direct ecommerce.

Required output

Structured door set, opening dimensions, finish and hardware codes, price, branded proposal and optional configured-order data.

What changes

Door family, opening width and height, headroom, left and right sideroom, reveal, depth, panel build, finish, windows, wicket door, track or lift system, motor, controls, access and safety equipment.

Rules to protect

Available door and track systems depend on opening geometry, roof condition, panel weight, lift height and use. Wicket doors, glazing, motors, springs, controls and safety devices must remain compatible with the selected system and market.

Price and action

Door family, opening size, panel construction, track package, springs, finish, glazing, wicket door, motor, controls, safety equipment, survey, removal, delivery and installation can follow retail or account price rules. Save the door, request a measured survey, create a dealer quote, submit it for technical review or pass an accepted configuration to the defined order workflow.

Required output

Structured opening and door specification, track and automation package, calculated price, branded quote, technical views and optional configured-order, BOM, spare-parts or service data.

What changes

Floor-to-floor height, stairwell length and width, upper-floor opening, flight arrangement, rise count, going, pitch, winders, landings, stringers, treads, risers, supports, balustrades, handrails, materials and finishes.

Rules to protect

The selected stair family must fit the available opening and construction system. Rise, going, pitch, walk line, headroom, landings, string intersections, tread support, post spacing, guarding and handrail transitions follow the manufacturer's accepted limits and review conditions.

Price and action

Stair family, flight and step counts, strings, treads, risers, landings, supports, balustrade length, posts, glass or infill, handrails, materials, finishes, survey, delivery and installation can use retail or dealer account rules. Save the staircase, request a measured survey, create a visual quote, submit the geometry for technical review or pass an accepted specification to the defined order and production-review workflow.

Required output

Structured stairwell and staircase geometry, selected construction and finishes, calculated price, branded quote, plans or elevations and optional BOM, cut-list, CAD, CAM, CNC, ERP or configured-order data defined and accepted in scope.

What changes

Run lengths, heights, corners, slopes, panel family, infill, posts, pedestrian gate, sliding or swing vehicle gate, motor, access control and finish.

Rules to protect

Panel counts follow measured runs and post spacing. Corners, gradients, gate clearances, opening direction, motor position and safety accessories affect the valid layout.

Price and action

Panels, cut panels, posts, corners, gates, motors, controls, foundations, delivery and installation can be calculated from quantity and site rules. Submit the property layout, request a site survey or generate a proposal that separates products, automation and installation.

Required output

Run-by-run quantities, gate specification, hardware and automation choices, price, plan snapshot and optional parts or order structure.

What changes

Footprint, height, wall modules, cladding, insulation package, roof, doors, windows, internal partitions, electrical package, heating, floor and foundation.

Rules to protect

Openings occupy valid wall modules, corners and structural zones remain clear, packages depend on room use and location, and roof or foundation choices follow the selected building system.

Price and action

Building size, module counts, envelope, openings, interior packages, services, foundation, delivery access and installation drive the result. Save a concept, qualify planning and access questions, request a detailed quote or pass a complete project to a design consultant.

Required output

Module layout, openings, room package, finish schedule, price, project assumptions, proposal imagery and optional order or BOM structure.

What changes

Single or multi-bay layout, width, length, height, roof type, posts, gutters, side screens, storage, frame finish, photovoltaic modules, charging and lighting.

Rules to protect

Bay spans, post positions, roof modules, drainage, vehicle clearances and optional solar or charging components depend on the chosen structural and electrical package.

Price and action

Structure, bay count, roof, finish, screens, storage, solar equipment, electrical accessories, foundations, delivery and installation can be priced as connected groups. Request a survey or engineering review, save the design for a commercial site or create an indicative proposal with defined assumptions.

Required output

Layout and dimensions, structure and roof selection, accessory and electrical packages, price, proposal and optional technical-handoff fields.

What changes

Roof, ground or canopy zones, module family, mounting package, inverter, optimizer, monitoring, battery storage, backup, EV charging, survey, services and commercial options.

Rules to protect

Modules, mounting systems, inverters, storage and electrical accessories must follow approved compatibility, quantity, market and review conditions. Imported yield or financial results retain their source and assumptions.

Price and action

Equipment, mounting, access, survey, design, permits, freight, labour, installation, commissioning and service can use installer or account-specific commercial rules. Save the project, request a survey, create a proposal or submit the selected system and assumptions for technical review.

Required output

Versioned site and equipment record, visual layout, commercial calculation, proposal, source and assumption fields, review status and optional BOM or order payload.

What changes

Straight, L-shaped or island layout, cabinet modules, worktop, grill, sink, fridge, storage, end panels, handles, finishes, utilities and delivery or installation.

Rules to protect

Appliances require compatible modules and clearances. Corners, fillers, end panels, worktop seams, gas, water and electrical requirements follow the selected layout.

Price and action

Cabinet modules, fronts, worktop area and cut-outs, appliances, fillers, utilities, delivery and installation roll into a line-level total. Save the layout, request a design review, buy standard packages or send a complete brief to a showroom consultant.

Required output

Module sequence, dimensions, finishes, appliance list, worktop details, price, quote imagery and optional order lines.

What changes

Opening dimensions, frame system, sash layout, opening direction, glazing, mullions, colour, hardware, sill, screen, shutter and installation condition.

Rules to protect

Maximum sash sizes, aspect ratios, glass make-up, hardware, ventilation and safety options vary by system, opening type and market.

Price and action

Frame perimeter or area, sash and mullion counts, glass, colour, hardware, accessories, survey, delivery and installation contribute to price. Build a schedule room by room, request measured pricing or submit a project to a dealer or fabricator.

Required output

Numbered window schedule, opening sizes, system and glazing codes, hardware, quantities, prices, proposal and optional order data.

What changes

Equipment family, capacity range, unit dimensions, enclosure size, panels, access doors, louvres, finish, base, acoustic treatment and service clearances.

Rules to protect

The selected unit needs defined airflow, access and maintenance clearances. Enclosure modules, panels, doors and acoustic options must remain compatible with equipment and site dimensions.

Price and action

Equipment or enclosure model, dimensions, panel and door quantities, finish, acoustic package, controls, delivery and installation can form a project price. Submit for technical review, create a sales proposal or export the selected enclosure and equipment references to the project workflow.

Required output

Equipment and enclosure specification, clearances, panels and accessories, price, drawings or images and optional order or BOM fields.

What changes

Available wall or room dimensions, module widths, heights and depths, doors, drawers, shelves, internal fittings, handles, finishes, lighting and installation.

Rules to protect

Modules must fit the available run, fillers and end panels close gaps, doors need opening clearance and internal accessories depend on compatible cabinet sizes.

Price and action

Cabinet modules, fronts, internal fittings, finish groups, panels, fillers, lighting, delivery and installation produce the total. Purchase a standard modular arrangement, save a room design or request a checked made-to-measure proposal.

Required output

Ordered module sequence, dimensional layout, finish and hardware selections, price, visual summary and optional part or order list.

What changes

Room walls and openings, straight, L-shaped, U-shaped or island layout, base, wall and tall cabinets, corners, fillers, panels, worktops, appliances, sinks, fronts, handles, finishes and installation services.

Rules to protect

Cabinets must fit the measured runs and selected range. Corners, neighbours, fillers, panels, plinths, worktop seams, appliance housings, ventilation, cut-outs and service zones remain compatible.

Price and action

Cabinets, dimensional adjustments, fronts, interiors, panels, worktops, cut-outs, appliances, delivery, survey and installation can follow retail or dealer account rules. Save the room and design, request a consultation, create a branded quote, continue to checkout for accepted ranges or submit the project for survey and technical review.

Required output

Structured room and cabinet layout, finishes, appliances, worktop details, calculated price, branded proposal and optional BOM, cut-list or configured-order data defined in scope.

What changes

Equipment family, duty, capacity, dimensions, modules, drive or control package, guards, connections, accessories, finish, documentation and service package.

Rules to protect

Performance ranges, interfaces, required components, incompatible options, regional electrical packages and review conditions must be explicit and versioned.

Price and action

Base equipment, configured modules, engineering options, controls, documentation, commissioning, freight and service can follow account and market rules. Create a budget quote, submit the configuration for engineering review or pass an approved project into CRM, ERP or order processing.

Required output

Versioned product specification, selected components, commercial calculation, proposal, approval status and optional configured-order or BOM payload.
